Avtech KPC 148E IR Box CCTV Camera

Avtech KPC 148E IR Box CCTV Camera























Specifications

Items Avtech KPC 148E
Pick up Element 1/3" HR color CCD image sensor
Number of Pixels 768(H) x 494(V) / 752(H) x 582(V))
Resolution 520 TV lines
Min. Illumination 0.3 Lux / F2.0, 0 Lux (IR ON)
IR LED 35 units
IR Effective Range Up to 35 meters
S/N Ratio More than 48dB (AGC off)
Electronic Shutter 1/60 (1/50) to 1/100,000 sec.
Lens F6.0mm / F2.0
Lens Angle 54�
IRIS Mode AES
AGC Auto
White Balance ATW
IP Rating IP67
Video Output 1.0 Vp-p composite, 75O
Operating Temperature 0?~40?
Power Source (�10%) DC12V
Current Consumption (�10%) 90mA (IR OFF); 450mA (IR ON)
Dimension (mm)** 75(�) � 142(H)
Weight 570g
